RUBINA RB-101D blindstitch sewing machine with SERVO motor

Type: Industrial blindstitch sewing machine

Brand: RUBINA

RUBINA RB-101D blindstitch sewing machine with integrated SERVO motor

The Rubina RB-101 blindstitch machine is a a great machine for tailors, dressmakers, and also for repairs or manufacturing. The ideal machine for your commercial and home projects including pant cuffs, felling slack bottoms, hemming dresses, skirt and coat bottoms, draperies, negligees, undergarments, lapel padding, blouses and sleeves. Uses integrated servo motor and has needle positioning.

Swing-Away work plate and swing-down narrow cylinder arm helps to sew in a circle. Very easy machine operation and adjustment. Easy to adjust needle depth for sewing on thicker materials. Skip mechanism enables the machine to sew 2:1 ratio.

SERVO motor adds these features:

  •  The machine runs quietly, the motor only works when the pedal is pressed.
  • There are no adverse vibrations.
  • Needle positioning (needle always stops at the highest or lowest point).
  • Ability to set a desired sewing speed.
  • Slow start, ensures an even speed up of the machine at the begging of the seam. This helps when sewing complicated parts since the machine is far more manageable.
  • Direct drive servo motor saves up to 70% energy comparing to a conventional electronic motor or clutch motor. Whereas older type servo motors save only up to 30%  energy.

If you have any questions or wish to know the price please inquire via email:  info@siuvimostilius.lt , phone +370 5 2733035 or press a button ‘Inquire’ and fill up a form.

General data
Fabric type Light, medium weight
Automatic lubrication system Yes
Automatic needle positioning Yes
Type of feed Bottom feed
Integrated servo motor (no belt) Yes
Swing-down narrow cylinder arm Yes
Swing-Away work plate Yes
Technical characteristics
Skip and non-skip stitch lever Yes
Skip mechanism 1:1 and 2:1
Stitch length, mm 3-8
Presser foot lift, mm 12
Cylinder Diameter, mm 57
Max sewing speed, rpm 2500
Needle system LWX6T Nr. 65-90
Power 550W
Voltage 220V
Warranty for industrial equipment: 12 months
